Inflatable Seal Profiles
Please see below a small selection of our available inflatable seal profiles with basic dimensions/ parameters.
We also have the ability to produce custom designs to clients specification, utilizing the latest 3D modelling software, and our vast industry experience.
We encourage interaction with our technical team prior to seal selection , and will assist swiftly with any technical support required.
We look forward to hearing from you
Reference | Thumbnail | Width | Height | Max Inflated Height | Standard Material(s) | View Profile |
---|---|---|---|---|---|---|
SP41A | ![]() | 6.6mm | 5.4mm | 6.5mm | Silicone / EPDM / FKM | View SP41A Profile |
SP71A | ![]() | 15mm | 10mm | 13mm | Silicone | View SP71A Profile |
SP61A | ![]() | 16mm | 11mm | 13mm | Silicone | View SP61A Profile |
SP143A | ![]() | 16mm | 15mm | 22mm | Silicone / EPDM | View SP143A Profile |
SP15A | ![]() | 16mm | 18mm | 20mm | Silicone | View SP15A Profile |
SP103A | ![]() | 16.5mm | 8mm | 15mm | Silicone | View SP103A Profile |
SP9A | ![]() | 16.9mm | 12mm | 18mm | Silicone / EPDM | View SP9A Profile |
SP101A | ![]() | 18mm | 12mm | 21mm | Silicone / EPDM | View SP101A Profile |
SP53A | ![]() | 20mm | 15mm | 28mm | Silicone / EPDM | View SP53A Profile |
SP21A | ![]() | 20mm | 17.5mm | 20mm | Silicone | View SP21A Profile |
SP65A | ![]() | 20mm | 20mm | 22mm | Silicone | View SP65A Profile |
SP49A | ![]() | 24mm | 16.5mm | 20mm | Silicone | VIew SP49A Profile |
SP29A | ![]() | 24mm | 23mm | 40mm | Silicone / Fluero-silicone | View SP29A Profile |
SP109A | ![]() | 25mm | 15mm | 25mm | Silicone / EPDM / FKM | View SP109A Profile |
SP83A | ![]() | 25mm | 15.5mm | 24mm | Silicone | View SP83A Profile |
SP19A | ![]() | 25mm | 18mm | 22mm | Silicone | View SP19A Profile |
SP93A | ![]() | 25mm | 18mm | 25mm | Silicone | View SP93A Profile |
SP95A | ![]() | 25.8mm | 20mm | 32mm | Silicone | View SP95A Profile |
SP69A | ![]() | 30mm | 20mm | 34mm | Silicone / EPDM | View SP69A Profile |
SP81A | ![]() | 34mm | 27mm | 35mm | Silicone | View SP81A Profile |
SP35A | ![]() | 35mm | 26.2mm | 50mm | Silicone / EPDM | View SP35A Profile |
SP17A | ![]() | 35mm | 32mm | 40mm | Silicone | View SP17A Profile |
SP73A | ![]() | 40mm | 32mm | 37mm | Silicone | View SP73A Profile |
SP23A | ![]() | 50mm | 24mm | 42mm | Silicone | View SP23A Profile |
SP23B | ![]() | 70mm | 33mm | 61mm | Silicone | View SP23B Profile |
SP75A | ![]() | 80mm | 12mm | 45mm | Silicone | View SP75A Profile |
Please be aware that the above data is a guideline only, and all performance/dimensional information cannot be taken for granted for each individual application.
